Handheld x-ray backscatter real time imaging system XRB-1
a compact, handheld single-side scanner
The system is a compact, handheld single-side scanner that can be used to scan objects in hard-to-reach places.With laser positioning, convenient to quickly determine the scanning position.
Request a Quote
Product Information
The handheld x-ray backscatter real time imaging system has high-performance .It is capable of detecting contrabands such as IEDs, metallic or non-metallic weapons, drugs, currency, and other organic threats etc.
Its compact and all-in-one portable design allows the operator to scan in hard-to-reach places, helping customs and law enforcement screen packages, vehicles, walls, doors, furniture, interlayers of airplane and train, the floor of the cargo storages etc.
Key Features
1) The system is a compact, handheld single-side scanner that can be used to scan objects in hard-to-reach places.
2) All-in-one design, 8-inch LCD display. The image is displayed in real time while the object is being scanned.
3) With laser positioning, convenient to quickly determine the scanning position.
4) Radiation safety: The radiation dose at the operator's position is ≤0.32μSv/h, which can ensure the safety of the operators and bystanders.
2) All-in-one design, 8-inch LCD display. The image is displayed in real time while the object is being scanned.
3) With laser positioning, convenient to quickly determine the scanning position.
4) Radiation safety: The radiation dose at the operator's position is ≤0.32μSv/h, which can ensure the safety of the operators and bystanders.
Test Items
Technical Data
1. The system is a compact, handheld single-side scanner that can be used to scan objects in hard-to-reach places.
2. All-in-one design, 8-inch display. The image is displayed in real time while the object is being scanned.
3. With laser positioning, convenient to quickly determine the scanning position.
4. Resolution：28AWG
5. Penetration: It can distinguish the organic glass or soap after 1mm steel plate.
6. Active area: When the equipment is 50 mm away from the object, the detection width is more than 160 mm and the length direction is unlimited.
7. Imaging speed：300mm/s
8. 4 hours operating time per battery charge (typical based on 25% duty cycle )
9. Overall dimensions: 324mm x 300mm x 143mm
10. All equipment can be placed in one instrument box.
11. Radiation safety: The radiation dose at the operator's position is ≤0.32μSv/h, which can ensure the safety of the operators and bystanders.
| X-ray generator power | 28W |
| Voltage of the x-ray source | 70Kev |
| Warning system when the source is turned on | To be equipped with this |
| Penetration distance | can distinguish the organic glass or soap after 1mm steel plate |
| Scan speed | 30cm/second |
| Imaging area | When the equipment is 50 mm away from the object, the detection width is more than 160 mm and the length direction is unlimited. |
| Display | 8inch LCD with touch screen |
| Display resolution | 1920*1200 pixels |
| Types of organic material detected | -Various types of explosives(PETN,RDX,black powder,C4,etc.) -Narcotics(heroin, methamphetamine,cocaine,oxycodone,etc.) -Cash,bearer bonds,etc. |
| Operating system | Android |
| Automatic shutdown system of X-ray generator when overheating | To be equipped with this |
| Built-in video camera | To be equipped with this |
| Built-in illuminator | To be equipped with this |
| Connectivity | Wi-Fi and USB interface |
| Possibility of image analysis | Inverted, smooth edge, enhance auto contrast, color contrast (11kinds), Image Stitch, On Screen Measurement, Save, etc. |
| Degree of climate protection | IP54 |
| Dimension | 324mm x 300mm x 143mm |
| Power supply | Rechargeable batteries |
| Working time | 4hours |
| Weight | 4.8kgs without battery |
| Operating temperature | -20 ºC to + 50 ºC |
