1. The system is a compact, handheld single-side scanner that can be used to scan objects in hard-to-reach places.

2. All-in-one design, 8-inch display. The image is displayed in real time while the object is being scanned.

3. With laser positioning, convenient to quickly determine the scanning position.

4. Resolution：28AWG

5. Penetration: It can distinguish the organic glass or soap after 1mm steel plate.

6. Active area: When the equipment is 50 mm away from the object, the detection width is more than 160 mm and the length direction is unlimited.

7. Imaging speed：300mm/s

8. 4 hours operating time per battery charge (typical based on 25% duty cycle )

9. Overall dimensions: 324mm x 300mm x 143mm

10. All equipment can be placed in one instrument box.

11. Radiation safety: The radiation dose at the operators position is ≤0.32μSv/h, which can ensure the safety of the operators and bystanders.
